Performance Data Sheet	Units	Value	Test Standard
General Properties
Density	g/cm³	1.49
Colour		Black
Max. Water Absorption  （+23℃ / 50% R.H.）	% by weight	1.1	DIN 53495
Max. Water Absorption	% by weight	4.6
DensitySliding Friction Coefficient against Steel	μ	0.15-0.35
Maximum PV Value (Dry Running)	MPa·m/s	0.70
Mechanical Properties
Modulus of Elasticity	MPa	9000	DIN 53457
Tensile Strength  （+20℃）	MPa	2500	DIN 53452
Compressive Strength	MPa	100
Recommended Max. Surface Pressure （ +20℃）	MPa	85
Shore D Hardness		80	DIN 53505
Physical & Thermal Properties
Max. Continuous Operating Temperature	°C	+150
Max. Short‑term Operating Temperature	°C	+220
Min. Operating Temperature	°C	-40	ASTM C 177
Thermal Conductivity	W/(m·K)	0.24
Thermal Expansion Coefficient （+23℃）	K⁻¹·10⁻⁵	8	DIN 53752
Electrical Properties
Volume Resistivity	Ω·cm	>10¹³	DIN IEC 93
Surface Resistivity	Ω	>10¹¹	DIN 53482
