WW (square linear carriage) - Zhejiang Savi Technology Co., Ltd.

It has a wide range of applications, suitable for automated mass production, special machinery manufacturing, underwater applications, food and pharmaceutical packaging industries. It can also perform well in extreme environments, meeting requirements such as corrosion resistance, chemical resistance, high-temperature resistance, low-temperature resistance, dust resistance, shock resistance and noise reduction.

About us

A national high-tech enterprise integrating the R&D, production and sales of professional maintenance-free self-lubricating materials. The company has obtained IATF 16949:2016 certification. For many years, Savi has been committed to optimizing the friction and wear properties of engineering plastics to meet industrial application requirements. Our main products include engineering plastic self-lubricating bearings, engineering plastic linear guide systems, engineering plastic spherical plain bearings, various series of wear-resistant rods, plates and wear-resistant granules.

A national high-tech enterprise integrating the research and development, production and sales of professional maintenance-free self-lubricating materials. The company has been certified to IATF 16949:2016. For many years, Savi has been dedicated to optimizing the friction and wear performance of engineering plastics for industrial applications. Our main products cover engineering plastic self-lubricating bearings, engineering plastic linear guide systems, engineering plastic spherical plain bearings, various series of wear-resistant rods, sheets and wear-resistant pellets.

Round‑Rail Slide Unit – Product Dimensions [mm]

Spec. Code	A Width	A2	C Length	C2	H2 ±0.25	K2	Wt. [g]	Max. Static Ld. Coy [N]	Max. Static Ld. Coz [N]	Max. Static Ld. Mox [Nm]	Max. Static Ld. Moy [Nm]	Max. Static Ld. Moz [Nm]
WW-06-30-06	54	45	60	51	18	M4	100	1680	840	25	34	34
WW-06-30-08	54	45	80	71	18	M4	110	1680	840	25	51	51
WW-06-30-10	54	45	100	91	18	M4	120	1680	840	25	68	68

Integrated Slide Unit – Product Dimensions [mm]

Spec. Code	A Width	A2	C Length	C2	H2 ±0.25	K2	Wt. [g]	Max. Static Ld. Coy [N]	Max. Static Ld. Coz [N]	Max. Static Ld. Mox [Nm]	Max. Static Ld. Moy [Nm]	Max. Static Ld. Moz [Nm]
WWC-06-30-06	54	45	60	51	16	M4	70	1680	840	25	34	34
WWC-06-30-08	54	45	80	71	16	M4	90	1680	840	25	51	51
WWC-06-30-10	54	45	100	91	16	M4	120	1680	840	25	68	68
WWC-10-40-10	73	60	100	87	22	M6	210	4800	2400	96	170	170
WWC-10-40-15	73	60	150	137	22	M6	320	4800	2400	96	290	290
WWC-10-40-20	73	60	200	187	22	M6	420	4800	2400	96	410	410
