Product Dimensions【mm】
| Spec. Code | d | B | H | H1 ±0.02 | L | S1 | S2 | S3 | E ±0.1 | N1 | N2 | SW | Wt. [kg] |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| WAC-06 | 6 | 16 | 27 | 15 | 32 | M5 | 4.2 | 8 | 22 | 11 | 13 | 2.5 | 0.03 |
| WAC-08 | 8 | 16 | 27 | 16 | 32 | M5 | 4.2 | 8 | 22 | 11 | 13 | 2.5 | 0.03 |
| WAC-10 | 10 | 18 | 33 | 18 | 40 | M6 | 5.2 | 10 | 27 | 13 | 16 | 3.0 | 0.05 |
| WAC-12 | 12 | 18 | 33 | 19 | 40 | M6 | 5.2 | 10 | 27 | 13 | 16 | 3.0 | 0.05 |
| WAC-14 | 14 | 20 | 38 | 20 | 45 | M6 | 5.2 | 10 | 32 | 13 | 18 | 3.0 | 0.07 |
| WAC-16 | 16 | 20 | 38 | 22 | 45 | M6 | 5.2 | 10 | 32 | 13 | 18 | 3.0 | 0.07 |
| WAC-20 | 20 | 24 | 45 | 25 | 53 | M8 | 6.8 | 11 | 39 | 18 | 22 | 4.0 | 0.12 |
| WAC-25 | 25 | 28 | 54 | 31 | 62 | M10 | 8.6 | 15 | 44 | 22 | 26 | 5.0 | 0.17 |
| WAC-30 | 30 | 30 | 60 | 34 | 67 | M10 | 8.6 | 15 | 49 | 22 | 29 | 5.0 | 0.22 |
| WAC-40 | 40 | 40 | 76 | 42 | 87 | M12 | 10.3 | 18 | 66 | 26 | 38 | 6.0 | 0.48 |
| WAC-50 | 50 | 50 | 92 | 50 | 103 | M16 | 14.25 | 20 | 80 | 34 | 46 | 8.0 | 0.82 |
