Product Dimensions【mm】
| D [mm] | L A S | s h8 [mm] | Wt. [kg/m] | L C S | s h6[mm] | Wt. [kg/m] | L E S不 | s h9 [mm] | Wt. [kg/m] | L max. [mm] |
|---|---|---|---|---|---|---|---|---|---|---|
| 6 | LAS-06-L | 0/-0.018 | 0.08 | LCS-06-L | -0.004/-0.012 | 0.23 | LES-06-L | 0/-0.030 | 0.23 | 1000 |
| 8 | LAS-08-L | 0/-0.022 | 0.14 | LCS-08-L | -0.005/-0.014 | 0.4 | LES-08-L | 0/-0.036 | 0.4 | 1000 |
| 10 | LAS-10-L | 0/-0.022 | 0.22 | LCS-10-L | -0.005/-0.014 | 0.6 | LES-10-L | 0/-0.036 | 0.6 | 3000 |
| 12 | LAS-12-L | 0/-0.027 | 0.32 | LCS-12-L | -0.006/-0.017 | 0.9 | LES-12-L | 0/-0.043 | 0.9 | 3000 |
| 16 | LAS-16-L | 0/-0.027 | 0.56 | LCS-16-L | -0.006/-0.017 | 1.58 | LES-16-L | 0/-0.043 | 1.58 | 3000 |
| 20 | LAS-20-L | 0/-0.033 | 0.88 | LCS-20-L | -0.006/-0.020 | 2.5 | LES-20-L | 0/-0.052 | 2.5 | 3000 |
| 25 | LAS-25-L | 0/-0.033 | 1.37 | LCS-25-L | -0.006/-0.020 | 3.9 | LES-25-L | 0/-0.052 | 3.9 | 3000 |
| 30 | LAS-30-L | 0/-0.033 | 1.48 | LCS-30-L | -0.006/-0.020 | 5.55 | LES-30-L | 0/-0.052 | 5.55 | 3000 |
