Product Features

The flange bearing design enables high-performance sliding bearings to be used where base hole tolerance requirements cannot be met. Although this bearing design imposes very low demands on base precision, it can still withstand high loads.

Maintenance-free flange bearings feature good self-lubricating property and long-term wear resistance, and can operate fully under dry running conditions.

Multiple materials are available according to operating conditions.

Easy installation, maintenance-free

Low precision requirement for mating housing holes

Suitable for rotary, oscillating and linear motion


Application scenarios:

Where flange bearings for threaded mounting are required

Where the snap ring of a clamp bearing cannot pass through the through hole

Where large tolerances exist

Where press-fit bearings cannot provide sufficient axial retention


Go to shopping

Scroll left/right to view the full table.

Product Dimensions【mm】                   Recommended shaft: h9

Spec. Code d1d1 Toleranced2d3d4d5d6d7 [ ±0.2 ]b1b2b3R
GFL-1010+0.025/+0.083123014154.5226214
GFL-1212+0.025/+0.083143616184.5266214.5
GFL-1414+0.025/+0.083164218215.5306215
GFL-1616+0.025/+0.083184820245.5346215.5
GFL-1818+0.025/+0.083205422276.5396217
GFL-2020+0.040/+0.124236026306.54410327
GFL-2525+0.040/+0.124287530356.55510328.5
GFL-3030+0.040/+0.124349036408.566103210

d1 tolerance after pressing into H7 housing bore (ISO3547‑1)


Installation:

Different installation methods can be adopted according to requirements.

For low radial loads, the flange bearing can be mounted onto a flat surface with only two bolts.

In cases of high radial loads, it is recommended to support the flange bearing using a hole on the reinforcement surface perpendicular to the load direction.

This hole allows relatively large tolerances, as it only provides auxiliary support for the flange bearing. To enable the bearing to withstand higher radial loads, the flange bearing can be press-fitted into the base hole with the recommended H7 tolerance. Auxiliary bolts secure the fit between the bearing and base.

No special materials or tools are required for installing maintenance-free flange bearings.
