规格代码	mm	mm	mm	d1压入后公差	d1压入后公差	孔径H7	孔径H7	轴径h9	轴径h9
NO.	d1	d2	L	Min.	Max.	Min.	Max.	Min.	Max.
EPH-0304-03	3	4.5	3	3.006	3.046	4.5	4.512	2.975	3
EPH-0304-05	3	4.5	5	3.006	3.046	4.5	4.512	2.975	3
EPH-0304-06	3	4.5	6	3.006	3.046	4.5	4.512	2.975	3
EPH-0405-04	4	5.5	4	4.01	4.058	5.5	5.512	3.97	4
EPH-0405-06	4	5.5	6	4.01	4.058	5.5	5.512	3.97	4
EPH-0506-05	5	6	5	5.01	5.04	6	6.012	4.97	5
EPH-0506-07	5	6	7	5.01	5.04	6	6.012	4.97	5
EPH-0507-05	5	7	5	5.01	5.058	7	7.015	4.97	5
EPH-0507-07	5	7	7	5.01	5.058	7	7.015	4.97	5
EPH-0507-08	5	7	8	5.01	5.058	7	7.015	4.97	5
EPH-0507-10	5	7	10	5.01	5.058	7	7.015	4.97	5
EPH-0608-05	6	8	5	6.01	6.058	8	8.015	5.97	6
EPH-0608-06	6	8	6	6.01	6.058	8	8.015	5.97	6
EPH-0608-08	6	8	8	6.01	6.058	8	8.015	5.97	6
EPH-0608-10	6	8	10	6.01	6.058	8	8.015	5.97	6
EPH-0608-15	6	8	15	6.01	6.058	8	8.015	5.97	6
EPH-0810-05	8	10	5	8.013	8.071	10	10.015	7.964	8
EPH-0810-06	8	10	6	8.013	8.071	10	10.015	7.964	8
EPH-0810-07	8	10	7	8.013	8.071	10	10.015	7.964	8
EPH-0810-08	8	10	8	8.013	8.071	10	10.015	7.964	8
EPH-0810-10	8	10	10	8.013	8.071	10	10.015	7.964	8
EPH-0810-12	8	10	12	8.013	8.071	10	10.015	7.964	8
EPH-0810-15	8	10	15	8.013	8.071	10	10.015	7.964	8
EPH-1012-2.7	10	12	2.7	10.013	10.071	12	12.018	9.964	10
EPH-1012-04	10	12	4	10.013	10.071	12	12.018	9.964	10
EPH-1012-05	10	12	5	10.013	10.071	12	12.018	9.964	10
EPH-1012-06	10	12	6	10.013	10.071	12	12.018	9.964	10
EPH-1012-07	10	12	7	10.013	10.071	12	12.018	9.964	10
EPH-1012-08	10	12	8	10.013	10.071	12	12.018	9.964	10
EPH-1012-09	10	12	9	10.013	10.071	12	12.018	9.964	10
EPH-1012-10	10	12	10	10.013	10.071	12	12.018	9.964	10
EPH-1012-12	10	12	12	10.013	10.071	12	12.018	9.964	10
EPH-1012-15	10	12	15	10.013	10.071	12	12.018	9.964	10
EPH-1012-20	10	12	20	10.013	10.071	12	12.018	9.964	10
EPH-1214-04	12	14	4	12.016	12.086	14	14.018	11.957	12
EPH-1214-05	12	14	5	12.016	12.086	14	14.018	11.957	12
EPH-1214-06	12	14	6	12.016	12.086	14	14.018	11.957	12
EPH-1214-08	12	14	8	12.016	12.086	14	14.018	11.957	12
EPH-1214-10	12	14	10	12.016	12.086	14	14.018	11.957	12
EPH-1214-12	12	14	12	12.016	12.086	14	14.018	11.957	12
EPH-1214-14	12	14	14	12.016	12.086	14	14.018	11.957	12
EPH-1214-15	12	14	15	12.016	12.086	14	14.018	11.957	12
EPH-1214-20	12	14	20	12.016	12.086	14	14.018	11.957	12
EPH-1214-25	12	14	25	12.016	12.086	14	14.018	11.957	12
EPH-1315-10	13	15	10	13.016	13.086	15	15.018	12.957	13
EPH-1315-15	13	15	15	13.016	13.086	15	15.018	12.957	13
EPH-1315-20	13	15	20	13.016	13.086	15	15.018	12.957	13
EPH-1315-25	13	15	25	13.016	13.086	15	15.018	12.957	13
EPH-1416-03	14	16	3	14.016	14.086	16	16.018	13.957	14
EPH-1416-06	14	16	6	14.016	14.086	16	16.018	13.957	14
EPH-1416-08	14	16	8	14.016	14.086	16	16.018	13.957	14
EPH-1416-10	14	16	10	14.016	14.086	16	16.018	13.957	14
EPH-1416-12	14	16	12	14.016	14.086	16	16.018	13.957	14
EPH-1416-15	14	16	15	14.016	14.086	16	16.018	13.957	14
EPH-1416-20	14	16	20	14.016	14.086	16	16.018	13.957	14
EPH-1416-25	14	16	25	14.016	14.086	16	16.018	13.957	14
EPH-1517-04	15	17	4	15.016	15.086	17	17.018	14.957	15
EPH-1517-10	15	17	10	15.016	15.086	17	17.018	14.957	15
EPH-1517-12	15	17	12	15.016	15.086	17	17.018	14.957	15
EPH-1517-15	15	17	15	15.016	15.086	17	17.018	14.957	15
EPH-1517-20	15	17	20	15.016	15.086	17	17.018	14.957	15
EPH-1517-25	15	17	25	15.016	15.086	17	17.018	14.957	15
EPH-1618-04	16	18	4	16.016	16.086	18	18.018	15.957	16
EPH-1618-08	16	18	8	16.016	16.086	18	18.018	15.957	16
EPH-1618-10	16	18	10	16.016	16.086	18	18.018	15.957	16
EPH-1618-12	16	18	12	16.016	16.086	18	18.018	15.957	16
EPH-1618-15	16	18	15	16.016	16.086	18	18.018	15.957	16
EPH-1618-20	16	18	20	16.016	16.086	18	18.018	15.957	16
EPH-1618-25	16	18	25	16.016	16.086	18	18.018	15.957	16
EPH-1618-30	16	18	30	16.016	16.086	18	18.018	15.957	16
EPH-1719-15	17	19	15	17.016	17.086	19	19.021	16.957	17
EPH-1719-20	17	19	20	17.016	17.086	19	19.021	16.957	17
EPH-1820-06	18	20	6	18.016	18.086	20	20.021	17.957	18
EPH-1820-10	18	20	10	18.016	18.086	20	20.021	17.957	18
EPH-1820-12	18	20	12	18.016	18.086	20	20.021	17.957	18
EPH-1820-15	18	20	15	18.016	18.086	20	20.021	17.957	18
EPH-1820-20	18	20	20	18.016	18.086	20	20.021	17.957	18
EPH-1820-25	18	20	25	18.016	18.086	20	20.021	17.957	18
EPH-1820-30	18	20	30	18.016	18.086	20	20.021	17.957	18
EPH-1820-40	18	20	40	18.016	18.086	20	20.021	17.957	18
EPH-2023-10	20	23	10	20.02	20.104	23	23.021	19.948	20
EPH-2023-15	20	23	15	20.02	20.104	23	23.021	19.948	20
EPH-2023-20	20	23	20	20.02	20.104	23	23.021	19.948	20
EPH-2023-25	20	23	25	20.02	20.104	23	23.021	19.948	20
EPH-2023-30	20	23	30	20.02	20.104	23	23.021	19.948	20
EPH-2225-15	22	25	15	22.02	22.104	25	25.021	21.948	22
EPH-2225-20	22	25	20	22.02	22.104	25	25.021	21.948	22
EPH-2225-25	22	25	25	22.02	22.104	25	25.021	21.948	22
EPH-2225-30	22	25	30	22.02	22.104	25	25.021	21.948	22
EPH-2225-35	22	25	35	22.02	22.104	25	25.021	21.948	22
EPH-2528-12	25	28	12	25.02	25.104	28	28.021	24.948	25
EPH-2528-15	25	28	15	25.02	25.104	28	28.021	24.948	25
EPH-2528-20	25	28	20	25.02	25.104	28	28.021	24.948	25
EPH-2528-24	25	28	24	25.02	25.104	28	28.021	24.948	25
EPH-2528-25	25	28	25	25.02	25.104	28	28.021	24.948	25
EPH-2528-30	25	28	30	25.02	25.104	28	28.021	24.948	25
EPH-2528-35	25	28	35	25.02	25.104	28	28.021	24.948	25
EPH-2528-50	25	28	50	25.02	25.104	28	28.021	24.948	25
EPH-2832-12	28	32	12	28.02	28.104	32	32.025	27.948	28
EPH-2832-15	28	32	15	28.02	28.104	32	32.025	27.948	28
EPH-2832-20	28	32	20	28.02	28.104	32	32.025	27.948	28
EPH-2832-23	28	32	23	28.02	28.104	32	32.025	27.948	28
EPH-2832-25	28	32	25	28.02	28.104	32	32.025	27.948	28
EPH-2832-30	28	32	30	28.02	28.104	32	32.025	27.948	28
EPH-3034-12	30	34	12	30.02	30.104	34	34.025	29.948	30
EPH-3034-15	30	34	15	30.02	30.104	34	34.025	29.948	30
EPH-3034-20	30	34	20	30.02	30.104	34	34.025	29.948	30
EPH-3034-24	30	34	24	30.02	30.104	34	34.025	29.948	30
EPH-3034-25	30	34	25	30.02	30.104	34	34.025	29.948	30
EPH-3034-30	30	34	30	30.02	30.104	34	34.025	29.948	30
EPH-3034-35	30	34	35	30.02	30.104	34	34.025	29.948	30
EPH-3034-40	30	34	40	30.02	30.104	34	34.025	29.948	30
EPH-3236-15	32	36	15	32.025	32.125	36	36.025	31.938	32
EPH-3236-20	32	36	20	32.025	32.125	36	36.025	31.938	32
EPH-3236-30	32	36	30	32.025	32.125	36	36.025	31.938	32
EPH-3236-40	32	36	40	32.025	32.125	36	36.025	31.938	32
EPH-3539-20	35	39	20	35.025	35.125	39	39.025	34.938	35
EPH-3539-25	35	39	25	35.025	35.125	39	39.025	34.938	35
EPH-3539-30	35	39	30	35.025	35.125	39	39.025	34.938	35
EPH-3539-40	35	39	40	35.025	35.125	39	39.025	34.938	35
EPH-3539-50	35	39	50	35.025	35.125	39	39.025	34.938	35
EPH-4044-10	40	44	10	40.025	40.125	44	44.025	39.938	40
EPH-4044-16	40	44	16	40.025	40.125	44	44.025	39.938	40
EPH-4044-20	40	44	20	40.025	40.125	44	44.025	39.938	40
EPH-4044-30	40	44	30	40.025	40.125	44	44.025	39.938	40
EPH-4044-40	40	44	40	40.025	40.125	44	44.025	39.938	40
EPH-4044-50	40	44	50	40.025	40.125	44	44.025	39.938	40
EPH-4550-10	45	50	10	45.025	45.125	50	50.025	44.938	45
EPH-4550-20	45	50	20	45.025	45.125	50	50.025	44.938	45
EPH-4550-22	45	50	22	45.025	45.125	50	50.025	44.938	45
EPH-4550-25	45	50	25	45.025	45.125	50	50.025	44.938	45
EPH-4550-30	45	50	30	45.025	45.125	50	50.025	44.938	45
EPH-4550-38	45	50	38	45.025	45.125	50	50.025	44.938	45
EPH-4550-40	45	50	40	45.025	45.125	50	50.025	44.938	45
EPH-5055-20	50	55	20	50.025	50.125	55	55.03	49.938	50
EPH-5055-25	50	55	25	50.025	50.125	55	55.03	49.938	50
EPH-5055-30	50	55	30	50.025	50.125	55	55.03	49.938	50
EPH-5055-40	50	55	40	50.025	50.125	55	55.03	49.938	50
EPH-5055-50	50	55	50	50.025	50.125	55	55.03	49.938	50
EPH-6065-30	60	65	30	60.03	60.15	65	65.03	59.926	60
EPH-6065-40	60	65	40	60.03	60.15	65	65.03	59.926	60
EPH-6065-50	60	65	50	60.03	60.15	65	65.03	59.926	60
EPH-6065-60	60	65	60	60.03	60.15	65	65.03	59.926	60
EPH-7075-60	70	75	60	70.03	70.15	75	75.03	69.926	70

材料性能	测试标准	单位	EPH
颜色	-	-	黑色
密度	ISO1183	g /cm³	1.70
最大吸湿率，50%RH	ISO62	%	0.1
最大吸水率	ISO62	%	0.3
对钢动摩擦系数	ITSO25	μ	0.07-0.20
极限P.V值	ITSO26	N/mm² x m/s	1.35
弯曲模量	ISO178	M Pa	12000
弯曲强度	ISO178	M Pa	165
最大静载荷	ITSO27	M Pa	90
最大动载荷	ITSO28	M Pa	50
邵氏硬度	ISO868	D	82
连续运行温度	ITS029	℃	+200
短时运行温度	ITS029	℃	+240
最低运行温度	ITSO29	℃	-40
导热性	ISO22007	W/(m·K)	0.60
线性热膨胀系数	ISO11359	K^-1 × 10^-5	4
阻燃等级	UL94	Class	V0
体电阻率	IEC60093	Ω.cm	>10⁵
面电阻率	IEC60093	Ω	>10⁵

材料性能

测试标准

单位

EPH

颜色

黑色

密度

ISO1183

g /cm³

1.70

最大吸湿率，50%RH

ISO62

0.1

最大吸水率

ISO62

0.3

对钢动摩擦系数

ITSO25

0.07-0.20

极限P.V值

ITSO26

N/mm² x m/s

1.35

弯曲模量

ISO178

M Pa

12000

弯曲强度

ISO178

M Pa

165

最大静载荷

ITSO27

M Pa

最大动载荷

ITSO28

M Pa

邵氏硬度

ISO868

连续运行温度

ITS029

℃

+200

短时运行温度

ITS029

℃

+240

最低运行温度

ITSO29

℃

-40

导热性

ISO22007

W/(m·K)

0.60

线性热膨胀系数

ISO11359

K^-1 × 10^-5

阻燃等级

UL94

Class

体电阻率

IEC60093

Ω.cm

>10⁵

面电阻率

IEC60093

>10⁵

EPH	干运行	油脂	油	水
摩擦系数 μ	0.25-0.40	0.09	0.04	0.04

EPH

干运行

油脂

油

水

摩擦系数 μ

0.25-0.40

0.09

0.04

直径 [mm]	EPH F10 [mm]	座孔 H7 [mm]	轴 h9 [mm]
> 0~3	+0.006~+0.046	0~+0.010	0~-0.025
> 3~6	+0.010~+0.058	0~+0.012	0~-0.030
> 6~10	+0.013~+0.071	0~+0.015	0~-0.036
> 10~18	+0.016~+0.086	0~+0.018	0~-0.043
> 18~30	+0.020~+0.104	0~+0.021	0~-0.052
> 30~50	+0.025~+0.125	0~+0.025	0~-0.062
> 50~80	+0.030~+0.150	0~+0.030	0~-0.074
> 80~120	+0.036~+0.176	0~+0.035	0~-0.087
> 120~180	+0.043~+0.203	0~+0.040	0~-0.100
