产品尺寸【mm】
| 产品代码 | d | A | B | H | H2 ±0.015 | S Φ | E | R | 重量 [kg] |
|---|---|---|---|---|---|---|---|---|---|
| TAF-08 | 8 | 65 | 12 | 23 | 12.5 | 5.5 | 52 | 32 | 0.04 |
| TAF-10 | 10 | 70 | 12 | 25 | 14.0 | 5.5 | 55 | 34 | 0.045 |
| TAF-12 | 12 | 85 | 14 | 32 | 18.0 | 6.6 | 70 | 42 | 0.09 |
| TAF-16 | 16 | 100 | 18 | 36 | 20.0 | 9.0 | 82 | 54 | 0.14 |
| TAF-20 | 20 | 130 | 20 | 46 | 25.0 | 11.0 | 108 | 72 | 0.25 |
| TAF-25 | 25 | 160 | 25 | 56 | 30.0 | 13.5 | 132 | 88 | 0.47 |
| TAF-30 | 30 | 180 | 25 | 64 | 35.0 | 13.5 | 150 | 96 | 0.62 |
| TAF-40 | 40 | 230 | 30 | 80 | 44.0 | 17.5 | 190 | 122 | 1.15 |
