产品尺寸【mm】
| 产品代码 | d | A | B | H | H2 ±0.015 | S Φ | E | R | 重量 [kg] |
|---|---|---|---|---|---|---|---|---|---|
| TA-08 | 8 | 65 | 12 | 22 | 11 | M5 | 52 | 32 | 0.04 |
| TA-10 | 10 | 70 | 12 | 21 | 10.5 | M5 | 55 | 34 | 0.037 |
| TA-12 | 12 | 85 | 14 | 28 | 14 | M6 | 70 | 42 | 0.07 |
| TA-16 | 16 | 100 | 18 | 32 | 16 | M8 | 82 | 54 | 0.13 |
| TA-20 | 20 | 130 | 20 | 42 | 21 | M10 | 108 | 72 | 0.22 |
| TA-25 | 25 | 160 | 25 | 52 | 26 | M12 | 132 | 88 | 0.44 |
| TA-30 | 30 | 180 | 25 | 58 | 29 | M12 | 150 | 96 | 0.56 |
| TA-40 | 40 | 230 | 30 | 72 | 36 | M16 | 190 | 122 | 1.0 |
