产品尺寸[mm]
| 产品代码 | d | 公差 | D | 公差 | L | T |
|---|---|---|---|---|---|---|
| BFLB-0407-05 | 4 | +0.000 /+0.020 | 7 | -0.00 /-0.015 | 5 | 1.5 |
| BFLB-0407-06 | 4 | +0.000 /+0.020 | 7 | -0.00 /-0.015 | 6 | 1.5 |
| BFLB-0508-05 | 5 | +0.000 /+0.020 | 8 | -0.00 /-0.015 | 5 | 1.5 |
| BFLB-0508-06 | 5 | +0.000 /+0.020 | 8 | -0.00 /-0.015 | 6 | 1.5 |
| BFLB-0508-08 | 5 | +0.000 /+0.020 | 8 | -0.00 /-0.015 | 8 | 1.5 |
| BFLB-0609-05 | 6 | +0.000 /+0.020 | 9 | -0.00 /-0.015 | 5 | 1.5 |
| BFLB-0609-06 | 6 | +0.000 /+0.020 | 9 | -0.00 /-0.015 | 6 | 1.5 |
| BFLB-0609-08 | 6 | +0.000 /+0.020 | 9 | -0.00 /-0.015 | 8 | 1.5 |
| BFLB-0609-10 | 6 | +0.000 /+0.020 | 9 | -0.00 /-0.015 | 10 | 1.5 |
| BFLB-0609-12 | 6 | +0.000 /+0.020 | 9 | -0.00 /-0.015 | 12 | 1.5 |
| BFLB-0811-06 | 8 | +0.000 /+0.020 | 11 | -0.00 /-0.015 | 6 | 1.5 |
| BFLB-0811-08 | 8 | +0.000 /+0.020 | 11 | -0.00 /-0.015 | 8 | 1.5 |
| BFLB-0811-10 | 8 | +0.000 /+0.020 | 11 | -0.00 /-0.015 | 10 | 1.5 |
| BFLB-0811-12 | 8 | +0.000 /+0.020 | 11 | -0.00 /-0.015 | 12 | 1.5 |
| BFLB-0811-15 | 8 | +0.000 /+0.020 | 11 | -0.00 /-0.015 | 15 | 1.5 |
| BFLB-1013-06 | 10 | +0.000 /+0.020 | 13 | -0.00 /-0.015 | 6 | 1.5 |
| BFLB-1013-08 | 10 | +0.000 /+0.020 | 13 | -0.00 /-0.015 | 8 | 1.5 |
| BFLB-1013-10 | 10 | +0.000 /+0.020 | 13 | -0.00 /-0.015 | 10 | 1.5 |
| BFLB-1013-12 | 10 | +0.000 /+0.020 | 13 | -0.00 /-0.015 | 12 | 1.5 |
| BFLB-1013-15 | 10 | +0.000 /+0.020 | 13 | -0.00 /-0.015 | 15 | 1.5 |
| BFLB-1013-20 | 10 | +0.000 /+0.020 | 13 | -0.00 /-0.015 | 20 | 1.5 |
| BFLB-1215-10 | 12 | +0.000 /+0.020 | 15 | -0.00 /-0.015 | 10 | 1.5 |
| BFLB-1215-12 | 12 | +0.000 /+0.020 | 15 | -0.00 /-0.015 | 12 | 1.5 |
| BFLB-1215-15 | 12 | +0.000 /+0.020 | 15 | -0.00 /-0.015 | 15 | 1.5 |
| BFLB-1215-20 | 12 | +0.000 /+0.020 | 15 | -0.00 /-0.015 | 20 | 1.5 |
| BFLB-1619-15 | 16 | +0.000 /+0.020 | 19 | -0.00 /-0.020 | 15 | 1.5 |
| BFLB-1619-20 | 16 | +0.000 /+0.020 | 19 | -0.00 /-0.020 | 20 | 1.5 |
| BFLB-1619-25 | 16 | +0.000 /+0.020 | 19 | -0.00 /-0.020 | 25 | 1.5 |
